BFGoodrich Mud-Terrain T/A KM3
Mud-Terrain T/A KM3
Off Road/Mud Terrain
Off Road/Mud Terrain
The BFGoodrich Mud-Terrain T/A KM3 was developed with race proven toughness derived from the success of the Baja KR3 in ultra rough off-road terrain. It's Coreguard technology helps prevent sidewall punctures while the Krawl-Tek compound grips to every surface at every angle. With extra attention paid to armor against shoulder damage and incredible aired down performance the Mud-Terrain KM3 takes the off-road environment seriously.
Write a Review
BFGoodrich Mud-Terrain T/A KM3 Tire Specs Chart
| Size | Diameter | Width | Rim Range |
Measured Rim |
Tread Depth |
Load Range |
Max Load |
Max psi |
Weight | Revs/Mile | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| LT 27X11R14 BSW |
27" | 11" | 6.5-9.5" | 9" | 18/32" | NA | 1650 lbs | 46 psi | 38 lbs | 770 | Show Specs |
|
| LT 27X9R14 89N BSW |
27" | 9" | 5-7.5" | 7" | 18/32" | NA | 1287 lbs | 42 psi | 33.4 lbs | 770 | Show Specs |
|
| LT 28X10.00R14 D BSW |
28" | 10" | 6-8.5" | 8" | 18/32" | D | 1557 lbs | 44 psi | 36.9 lbs | 743 | Show Specs |
|
| LT 29X9R14 94N BSW |
29" | 9" | 5-7.5" | 7" | 18/32" | NA | 1474 lbs | 42 psi | 36.4 lbs | 717 | Show Specs |
|
| 30X10.00R14UTV 100Q D BSW |
30" | 10" | 6-8.5" | 8" | 18/32" | D | 1760 lbs | 44 psi | 40.3 lbs | 693 | Show Specs |
|
| LT 32X10.00R14 104Q D BSW |
32" | 10" | 6-8.5" | 8" | 18/32" | D | 2002 lbs | 44 psi | 42.5 lbs | 650 | Show Specs |
|
| LT 215/75R15 100/97Q C BSW |
27.7" | 8.5" | 5.5-7" | 6" | 18/32" | C | 1765/1610 lbs | 50 psi | 40 lbs | 751 | Show Specs |
|
| LT 235/75R15 110/107Q D BSW |
28.9" | 9.3" | 6-7" | 6.5" | 18/32" | D | 2335/2150 lbs | 65 psi | 47.8 lbs | 721 | Show Specs |
|
| 30X10.00R15UTV 99Q D BSW |
30" | 10" | 6-8.5" | 8" | 18/32" | D | 1694 lbs | 44 psi | 39.7 lbs | 693 | Show Specs |
|
| LT 30X9.50R15 104Q C BSW |
29.5" | 9.5" | 6.5-8.5" | 7.5" | 18/32" | C | 1985 lbs | 50 psi | 46.3 lbs | 705 | Show Specs |
|
| LT 31X10.50R15 109Q C BSW |
30.5" | 10.6" | 7-9" | 8.5" | 18/32" | C | 2270 lbs | 50 psi | 51.3 lbs | 682 | Show Specs |
|
| 32X10.00R15UTV 103Q D BSW |
32" | 10" | 6-8.5" | 8" | 18/32" | D | 1936 lbs | 44 psi | 44 lbs | 650 | Show Specs |
|
| LT 32X11.50R15 113Q C BSW |
31.5" | 11.4" | 8-10" | 9" | 18/32" | C | 2535 lbs | 50 psi | 55.2 lbs | 659 | Show Specs |
|
| LT 33X10.50R15 114Q C BSW |
32.5" | 10.6" | 7-9" | 8.5" | 18/32" | C | 2600 lbs | 50 psi | 56.7 lbs | 640 | Show Specs |
|
| LT 33X12.50R15 108Q C BSW |
32.5" | 12.5" | 8.5-11" | 10" | 18/32" | C | 2205 lbs | 35 psi | 59.9 lbs | 640 | Show Specs |
|
| LT 35X12.50R15 113Q C BSW |
34.5" | 12.5" | 8.5-11" | 10" | 18/32" | C | 2535 lbs | 35 psi | 64.8 lbs | 602 | Show Specs |
|
| LT 225/75R16 115/112Q E BSW |
29.3" | 8.8" | 6-7" | 6" | 18/32" | E | 2680/2470 lbs | 80 psi | 48 lbs | 710 | Show Specs |
|
| LT 235/70R16 110/107Q D BSW |
29" | 9.5" | 6-7.5" | 7" | 18/32" | D | 2335/2150 lbs | 65 psi | 48 lbs | 718 | Show Specs |
|
| LT 235/85R16 120/116Q E BSW |
NA | NA | 6-7.5" | 6.5" | 18/32" | E | 3042/2756 lbs | 80 psi | 54 lbs | NA | Show Specs |
|
| LT 245/75R16 120/116Q E BSW |
30.5" | 9.8" | 6.5-8" | 7" | 18/32" | E | 3085/2755 lbs | 80 psi | 53 lbs | 683 | Show Specs |
|
| LT 255/70R16 120/117Q E BSW |
30.1" | 10.2" | 6.5-8" | 7.5" | 18/32" | E | 3085/2835 lbs | 80 psi | 55 lbs | 691 | Show Specs |
|
| LT 255/85R16 123/120Q E BSW |
33.1" | 10" | 6.5-8" | 7" | 18/32" | E | 3415/3085 lbs | 80 psi | 59 lbs | 629 | Show Specs |
|
| LT 265/70R16 121/118Q E BSW |
30.6" | 10.7" | 7-8.5" | 8" | 18/32" | E | 3195/2910 lbs | 80 psi | 58 lbs | 679 | Show Specs |
|
| LT 265/75R16 119/116Q D BSW |
31.7" | 10.5" | 7-8" | 7.5" | 18/32" | D | 3000/2755 lbs | 65 psi | 59 lbs | 657 | Show Specs |
|
| LT 265/75R16 123/120Q E BSW |
31.7" | 10.5" | 7-8" | 7.5" | 18/32" | E | 3415/3085 lbs | 80 psi | 59.4 lbs | 657 | Show Specs |
|
| LT 285/75R16 126/123Q E BSW |
32.8" | 11.3" | 7.5-9" | 8" | 18/32" | E | 3750 lbs | 80 psi | 64.5 lbs | 634 | Show Specs |
|
| LT 305/70R16 124/121Q E BSW |
32.8" | 12.2" | 8-9.5" | 9" | 18/32" | E | 3525/3195 lbs | 65 psi | 68 lbs | 634 | Show Specs |
|
| LT 315/75R16 127/124Q E BSW |
34.6" | 12.3" | 8-11" | 8.5" | 18/32" | E | 3860/3525 lbs | 65 psi | 73.2 lbs | 602 | Show Specs |
|
| 7.50R16 116/112Q E BSW |
31.8" | 8.7" | 5.5-7" | 6" | 18/32" | E | 2755 lbs | 80 psi | 50.46 lbs | 654 | Show Specs |
|
| LT 245/70R17 119/116Q E BSW |
30.6" | 9.8" | 6.5-8" | 7" | 18/32" | E | 3000/2755 lbs | 80 psi | 56 lbs | 681 | Show Specs |
|
| LT 255/65R17 114/110Q D BSW |
30.1" | 10.2" | 7-9" | 7.5" | 18/32" | D | 2600/2335 lbs | 65 psi | 54 lbs | 691 | Show Specs |
|
| LT 255/75R17 111/108Q C BSW |
32.1" | 10" | 6.5-8.5" | 7" | 18/32" | C | 2405/2205 lbs | 50 psi | 54.63 lbs | 649 | Show Specs |
|
| LT 265/65R17 120/117Q E BSW |
30.6" | 10.7" | 7.5-9.5" | 8" | 18/32" | E | 3085/2835 lbs | 80 psi | 56 lbs | 681 | Show Specs |
|
| LT 265/70R17 121/118Q E BSW |
31.7" | 10.7" | 7-8.5" | 8" | 18/32" | E | 3195/2910 lbs | 80 psi | 57.5 lbs | 657 | Show Specs |
|
| LT 285/70R17 121/118Q E BSW |
32.8" | 11.5" | 7.5-9" | 8.5" | 18/32" | E | 3195/2910 lbs | 80 psi | 67.1 lbs | 635 | Show Specs |
|
| LT 285/75R17 121/118Q E BSW |
33.9" | 11.3" | 7.5-9.5" | 8" | 18/32" | E | 3195/2910 lbs | 80 psi | 67.2 lbs | 614 | Show Specs |
|
| LT 295/70R17 121/118Q E BSW |
33.3" | 11.8" | 7.5-10" | 8.5" | 18/32" | E | 3195/2910 lbs | 80 psi | 68.3 lbs | 624 | Show Specs |
|
| LT 315/70R17 121/118Q E BSW |
34.4" | 12.7" | 8-11" | 9.5" | 18/32" | E | 3195/2910 lbs | 65 psi | 65.8 lbs | 604 | Show Specs |
|
| LT 33X12.50R17 120Q E BSW |
32.5" | 12.5" | 8.5-11" | 10" | 18/32" | E | 3085 lbs | 65 psi | 67.6 lbs | 640 | Show Specs |
|
| LT 35X12.50R17 121Q E BSW |
34.5" | 12.5" | 8.5-11" | 10" | 18/32" | E | 3195 lbs | 65 psi | 74.4 lbs | 602 | Show Specs |
|
| LT 37X12.50R17 124Q D BSW |
36.5" | 12.5" | 8.5-11" | 10" | 18/32" | D | 3525 lbs | 50 psi | 77.4 lbs | 569 | Show Specs |
|
| LT 37X13.50R17 121Q E BSW |
36.5" | 13.6" | 8.5-11" | 11" | 18/32" | E | 3195 lbs | 65 psi | 81.4 lbs | 554 | Show Specs |
|
| LT 39X13.50R17 121Q C BSW |
38.5" | 13.6" | 8.5-11" | 11" | 18/32" | C | 3195 lbs | 35 psi | 88.8 lbs | 540 | Show Specs |
|
| LT 265/60R18 119/116Q E BSW |
30.5" | 10.7" | 7.5-9.5" | 8" | 18/32" | E | 3000/2755 lbs | 80 psi | 57 lbs | 682 | Show Specs |
|
| LT 275/65R18 123/120Q E BSW |
32.1" | 11" | 7.5-9" | 8" | 18/32" | E | 3415/3085 lbs | 80 psi | 63.1 lbs | 648 | Show Specs |
|
| LT 275/70R18 125/122Q E BSW |
33.2" | 11" | 7-8.5" | 8" | 18/32" | E | 3640/3305 lbs | 80 psi | 62.3 lbs | 627 | Show Specs |
|
| LT 285/65R18 125/122Q E BSW |
32.6" | 11.5" | 8-10" | 8.5" | 18/32" | E | 3640/3305 lbs | 80 psi | 67 lbs | 639 | Show Specs |
|
| LT 285/70R18 127/124Q E BSW |
33.7" | 11.5" | 7.5-9.5" | 8.5" | 18/32" | E | 3860/3525 lbs | 80 psi | 63 lbs | 616 | Show Specs |
|
| LT 295/70R18 129/126Q E BSW |
34.3" | 11.8" | 7.5-10" | 8.5" | 18/32" | E | 4080/3750 lbs | 80 psi | 73.7 lbs | 607 | Show Specs |
|
| LT 305/60R18 121/118Q E BSW |
32.4" | 12.2" | 8.5-11" | 9" | 18/32" | E | 3195/2910 lbs | 65 psi | 69 lbs | 642 | Show Specs |
|
| LT 325/65R18 127/124Q E BSW |
NA | NA | 9-12" | 9.5" | 18/32" | E | 3860/3525 lbs | 65 psi | 76 lbs | NA | Show Specs |
|
| LT 33X12.50R18 118Q E BSW |
32.5" | 12.5" | 8.5-11" | 10" | 18/32" | E | 2910 lbs | 65 psi | 69.4 lbs | 640 | Show Specs |
|
| LT 35X12.50R18 123Q E BSW |
34.5" | 12.5" | 8.5-11" | 10" | 18/32" | E | 3415 lbs | 65 psi | 72.9 lbs | 602 | Show Specs |
|
| LT 37X12.50R18 128Q E BSW |
36.5" | 12.5" | 8.5-11" | 10" | 18/32" | E | 3970 lbs | 65 psi | 78.97 lbs | 569 | Show Specs |
|
| LT 37X13.50R18 128Q E BSW |
36.5" | 13.6" | 8.5-11" | 11" | 18/32" | E | 3970 lbs | 65 psi | 80 lbs | 569 | Show Specs |
|
| LT 275/65R20 126/123Q E BSW |
34.1" | 11" | 7.5-9.5" | 8" | 18/32" | E | 3750/3415 lbs | 80 psi | 66.84 lbs | 610 | Show Specs |
|
| LT 285/55R20 122/119Q E BSW |
32.4" | 11.7" | 8-10" | 9" | 18/32" | E | 3305/3000 lbs | 80 psi | 65.1 lbs | 643 | Show Specs |
|
| LT 295/55R20 123/120Q E BSW |
32.8" | 12.2" | 8-10" | 9.5" | 18/32" | E | 3415/3085 lbs | 80 psi | 67 lbs | 635 | Show Specs |
|
| LT 295/60R20 126/123Q E BSW |
33.9" | 11.8" | 8-10" | 8.5" | 18/32" | E | 3750/3415 lbs | 80 psi | 73.5 lbs | 613 | Show Specs |
|
| LT 295/65R20 129/126Q E BSW |
35.1" | 11.8" | 8-10" | 8.5" | 18/32" | E | 4080/3750 lbs | 80 psi | 76 lbs | 592 | Show Specs |
|
| LT 305/55R20 121/118Q E BSW |
33.2" | 12.4" | 8.5-11" | 9.5" | 18/32" | E | 3195/2910 lbs | 65 psi | 71.6 lbs | 626 | Show Specs |
|
| LT 325/60R20 126/123Q E BSW |
35.4" | 13" | 9-12" | 9.5" | 18/32" | E | 3750/3415 lbs | 65 psi | 77.8 lbs | 588 | Show Specs |
|
| LT 33X12.50R20 114Q E BSW |
32.5" | 12.5" | 8.5-11" | 10" | 18/32" | E | 2600 lbs | 65 psi | 67.2 lbs | 640 | Show Specs |
|
| LT 35X12.50R20 121Q E BSW |
34.5" | 12.5" | 8.5-11" | 10" | 18/32" | E | 3195 lbs | 65 psi | 74.5 lbs | 602 | Show Specs |
|
| LT 37X12.50R20 126Q E BSW |
36.5" | 12.5" | 8.5-11" | 10" | 18/32" | E | 3750 lbs | 65 psi | 79.9 lbs | 569 | Show Specs |
|
| LT 37X13.50R20 127Q E BSW |
36.5" | 13.6" | 8.5-11" | 11" | 18/32" | E | 3860 lbs | 65 psi | 82.5 lbs | 569 | Show Specs |
|
| LT 37X13.50R22 123Q E BSW |
36.5" | 13.5" | 8.5-11" | 11" | 18/32" | E | 3415 lbs | 65 psi | NA | 569 | Show Specs |
